Scylon Models
| SCYLON FRAME SPECIFICATIONS |
|
|---|---|
|
FRAME MATERIAL Gen 2 Braided Carbon M46J / T800 Carbon Fiber Layup |
SEATPOST DIAMETER Proprietary SCYLON Aero Carbon, -20/+10mm SB |
|
SIZES XXS, XS, SM, MD, LG, XL |
SEATPOST CLAMP Semi-Integrated TIME CNC Alloy |
|
FORK STEERER TUBE Kevlar Enhanced BCS Carbon Fiber - Tapered 1–1/8” to 1–1/2” |
SHIFTING Compatible with all Electronic Shifting Systems |
|
HEADSET BEARINGS FSA NO.69 SRS |
FRONT DERAILLEUR Standard Mount |
|
WHEEL SIZE 700c |
REAR DERAILLEUR Standard Mount |
|
MAXIMUM TIRE WIDTH 700x32 |
BRAKE TYPE Front and Rear Flat Mount Disc |
|
BOTTOM BRACKET PF 386 EVO |
ROTOR SIZE 140/160mm with Adapter |
|
THRU AXLES 12x120x1.5mm pitch Front, 12x159x1.5mm pitch Rear |
|
| WHAT'S INCLUDED |
|
|---|---|
|
FSA Headset/SRS Topcap for Semi & Fully-Integrated Cockpits |
Front and Rear Thru Axles |
| Alloy Bottle Bolts | Semi-Integrated Seatpost Clamp |
| Scylon Aero Seatpost |
Front and Rear Derailleur Hangers |
Geometry
