ADHX 45 COULD BE YOUR TIME IF:
-
Google Maps can't figure out where you are most of the time
-
What appears to be a vicious sock tan wipes off with a wet washcloth
-
You know exactly where that Forest Service road connects, and HIGHLY recommend it
-
You don't own a pump gauge that goes past 60psi
Ready to Paint
Time framesets can be purchased unpainted in a prepped and sanded condition and with all hardware. Deliver the Ready to Paint frameset to the paint shop of your choosing to create the TIME of your dreams!
What's Included
• DEDA S DCR Headset for Semi & Fully-Integrated Cockpits• Front and Rear Thru Axles
• Alloy Bottle Bolts
• Integrated Seatpost Clamp
• (1) Derailleur Hanger
• Single Cover and Drivetrain Conversion Kit
• Alloy Bottle Bolts
• Integrated Seatpost Clamp
• (1) Derailleur Hanger
• Single Cover and Drivetrain Conversion Kit
| ADHX 45 FRAME SPECIFICATIONS | |
|---|---|
|
FRAME MATERIAL BCS Carbon Fiber - Dyneema® Enhanced |
THRU AXLES 12x120x1.5mm Pitch F, 12x159x1.5 Pitch R |
|
SIZES XS, SM, MD, LG, XL |
SEATPOST DIAMETER ø27.2mm |
|
FORK STEERER TUBE Tapered 1-1/8" to 1-1/2" |
SEATPOST CLAMP Proprietary ADHX Alloy |
|
HEADSET BEARINGS Top and Bottom 1-1/2" (with internal routing compression ring) |
SHIFTING Compatible with Electronic and Standard Shifting Systems |
|
WHEEL SIZE 700c/650b |
FRONT DERAILLEUR 1X and 2X Wide Compatible with Integrated Single Cover and Drivetrain Conversion Kit |
MAXIMUM TIRE WIDTH
|
REAR DERAILLEUR Standard Mount |
|
BOTTOM BRACKET PF BB386 |
BRAKE TYPE Front and Rear Flat Mount Disc |
|
DISC HUB STANDARD 12x100mm F, 12x142mm R |
ROTOR SIZE 140/160mm with Adapter |
Geometry
Ordering // What to Expect
Buying a bike from our online store is simple and convenient… but what does it look like when your TIME arrives? We have several options and flexible shipping configurations.
Framesets
TIME bikes are available as framesets ready to build up into your dream bike.
Complete Bikes
TIME can ship your new bike in two ways: Assembled and Tuned in an XL Bikeflights Carton or in several smaller boxes requiring assembly. Our customers know which they prefer, so we accommodate your preference.
United States Customers
You will be billed standard State and Local sales tax which varies by your location.
International Customers
• Purchases may be subject to Import Duties or Tax which vary by your location outside the USA.
• At check-out you pay Time Bicycles the price of the frame and shipping without any additional Import Duties or Tax added.
• Any Import Duties or Tax on your purchase will be due on delivery to the shipping carrier, who may charge an additional brokerage fee.
