ADHX

FOR ALL ROADS TRAVELED

There are many reasons the ADHX could be your TIME - What's YOUR X-Factor? ADHX is the first of its kind to incorporate Bio-Based Dyneema®, the World’s Strongest Fiber®, BCS (Braided Carbon Structure) and RTM (Resin Transfer Moulding) to build the ultimate Fast Gravel machine.

ULTRA strength

Bio-Based Dyneema® is Lighter, Stronger and Smarter. Because we weave our own braided carbon structures (BCS) we have been able to add a hybrid Carbon/Bio-Based Dyneema® layer that increases strength in the structure without compromising stiffness or weight.

DYNEEMA® TECH

Sublime ride feel

Braided Carbon Structure is the weaving of dry fibers into complex bi-directional ‘socks.’ These tubes of fiber are easy to tune with different materials. BCS also allows something that is unheard of in the cycling world; continuous fibers that run the full length of a structure.

BCS TECH

HIGHEST QUALITY

Resin Transfer Moulding is the best way to mould carbon. By laying up dry fibers and then injecting resin at high pressure between rigid external AND internal molds, air pockets and voids are eliminated. Unlike prepreg air bag moulding, RTM quality is uniform and consistent.

RTM TECH

ADHX - Review

"If you know, you know."

Tim Cruz breaks down his first impressions of his custom ADHX build

VIEW ON YOUTUBE

ADHX - BUILD

"I want one. I want one right now!"

Backyard Bicycles in Gateshead/Newcastle go in-depth to show us the build process

VIEW ON YOUTUBE

FRAME SPECIFICATIONS

ADHX FRAME SPECIFICATIONS
FRAME MATERIAL
BCS Carbon Fiber - Dyneema® Enhanced
THRU AXLES
12x120x1.5mm Pitch F, 12x159x1.5 Pitch R
SIZES
XS, SM, MD, LG, XL
SEATPOST DIAMETER
ø 27.2mm
FORK STEERER TUBE
Tapered 1-1/8" to 1-1/2"
SEATPOST CLAMP
Proprietary ADHX Alloy
HEADSET BEARINGS
Top and Bottom 1-1/2" (with internal routing compression ring)
SHIFTING
Compatible with Electronic and Standard Shifting Systems
WHEEL SIZE
700c
FRONT DERAILLEUR
1X and 2X Compatible with Integrated Single Cover and Drivetrain Conversion Kit
MAXIMUM TIRE WIDTH
  • 700 x 28-38c Road Tires (Slick or File Tread)
  • 700 x 32-35c Cross Tires (Low Profile Knob)
  • (not all tire/rim combinations fit with adequate clearance - check for appropriate fit)
REAR DERAILLEUR
Standard Mount
BOTTOM BRACKET
PF BB386
BRAKE TYPE
Front and Rear Flat Mount Disc
DISC HUB STANDARD
12x100mm F, 12x142mm R
ROTOR SIZE
140/160mm with Adapter

GEOMETRY

ADHX

SUSTAINABILITY

TIME didn’t necessarily start with the idea of making more efficient use of materials, but in fact many of our processes are less wasteful than industry-standard carbon production. It’s not a secret that working with carbon is not a green practice, but this doesn’t mean there’s no value in using cleaner methods – reducing and reusing whenever possible and meeting or exceeding strict EU environmental impact guidelines.

COMPLETE INFO & TECH
